Bently Nevada 2300 Series Vibration Monitor

The Bently Nevada 2300 Series Vibration Monitor provides cost-effective, continuous vibration monitoring and protection for less critical or spare machinery. It is designed to safeguard medium- to low-criticality machinery across industries such as oil & gas, power generation, water treatment, pulp and paper, manufacturing, mining, and cement.

The Bently Nevada 2300 Series Vibration Monitor measure vibration and issue high-level alarms using two channels for seismic or proximity inputs, a speed input for time-synchronous measurements, and relay outputs. The 2300/20 model offers a configurable 4–20 mA output for DCS integration, while the 2300/25 supports System 1 connectivity via Trendmaster SPA. These monitors suit a wide range of machine trains or individual casings, delivering advanced signal processing wherever the sensor count matches the channel capacity.

QInstrument is a leading supplier of Bently Nevada 2300 Series Vibration Monitor in UK and Ireland (EU), offering competitive prices and fast worldwide shipping across Turkey, Saudi Arabia, Oman, Nigeria, Indonesia, Malaysia, Vietnam, Mexico, Brazil, Argentina, and Colombia. Buy Bently Nevada Vibration Monitor from one of the UK’s leading suppliers of industrial automation and instrumentation equipment.

Features of Bently Nevada 2300 Series Vibration Monitor

• Two-channel device
• Compact, stand-alone vibration monitoring
• Two relay outputs with programmable setpoints
• Ethernet 10/100 Base-T communication
• Continuous monitoring and protection
• Three buffered transducer outputs
• LCD display
• Two acceleration inputs

Technical Specifications of Bently Nevada 2300 Series Vibration Monitor

• Channels: 2 vibration + 1 speed/Keyphasor
• Input types: Seismic, proximity, velocity, accelerometer, magnetic pickup
• Frequency range: ~0.2 Hz to ~20 kHz
• Outputs: Vibration, velocity, displacement, acceleration, speed
• 4–20 mA outputs: 2 proportional loop-powered (1 % accuracy)
• Relay outputs: 2 programmable for alarm/shutdown
• Buffered outputs: 3 sensor outputs with EMI protection
• Display: LCD + LED indicators for measurement and alarms
• Communication: Ethernet 10/100 Base‑T, Modbus®
• Power: 18–36 Vdc, ~7.5 W max
• Operating temp: –30 °C to +65 °C, 95 % non‑condensing
• Proximity interface: ~‑23 Vdc, 15 mA, 10 kΩ input
• RPM range: Up to 120,000 RPM
• Mounting: Panel or DIN‑rail, compact enclosure
• Certifications: CE, CSA, ATEX/IECEx options

Vibration Monitor Part Number & Configuration Guide

Standard (Example) Part Number

2300/20-00

This is a reference configuration for the Bently Nevada 2300 Series Vibration Monitor. It represents one commonly supplied setup and helps customers understand how the part number is structured.

Configurable Part Number Format

2300/XX-XX

Each X / XX in the part number indicates a selectable option that can be customized based on your application requirements such as Output & Approvals.

✅ Important: Final part number depends on the exact configuration needed for your machinery, environment, and monitoring system.

Applications

The Bently Nevada 2300 Series Vibration Monitor is commonly used in monitoring industrial rotating equipment, including:

• Steam and gas turbines
• Centrifugal and axial compressors
• Industrial pumps and motors
• Generators and high-speed rotating equipment
• Applications requiring continuous vibration monitoring, high-level alarms, and optional DCS or SPA integration

Downloadable

Bently Nevada 2300 Series Vibration Monitor Product Specifications
